In Part 1… I talked about three specific areas of electronic production that are often lacking in demos submitted to myself and EDM labels. It is impossible to fit a comprehensive list of every issue producers encounter into one or even several articles. I will, however, continue my general discussion on techniques that can implement drastic improvement to your overall production. If you’re already familiar with these tips, they can still serve as a good reference before submitting a mix.



4) BASS IS WEAK



In past articles, I have heavily emphasized the role that a sub plays in EDM tracks. To put it simply, the sub low frequencies move the most air and cause the most vibrations in a club. This is, in essence, what differentiates a live DJ performance from listening to their songs on a consumer system or headphones.



What is a sub?



Sub refers to an instrument that is rooted in subsonic frequency content. The instrument is essentially a sine wave, usually playing the root of the harmony or melody in a register below about 100 Hz. Since a sine wave only contains the fundamental of a tone, it won’t conflict with mid and high frequencies.

In Massive, you get a sine wave by switching an oscillator to the Sine-Square setting and moving the wavetable position to the left-most position.



Top Mistakes 2 - Massve - Sub Oscillator



Below is a graphical representation of this sub oscillator playing note G-0. As you can see, there is a sharp decline in the level of frequency content above 100 Hz.



Top Mistakes 2 - Massive - Sub Analysis



Splitting the Sub and Bass



Bass instruments in many popular EDM tracks seem to have a wide stereo spread, but the frequencies below 100 Hz  are not responsible for this. Those frequencies should remain monophonic because of the high potential for interference. Instead, you can expand the image by layering something on top of the sub and widening that layer. You should high-pass filter it above 100 Hz to make sure it’s not conflicting with the actual sub. Together, the two layers give the impression that the whole bass is wide.

An important advantage of splitting the bass and the sub is the ability to process the top layer more extensively without damaging the clarity of the sub frequencies (below 100 Hz). You could add a layer of audible grit while retaining the frequencies needed to give the track a solid presence in a live setting.

This instrument is made up of two layers. The first is a mid bass layer I made in Massive and the second is a simple sine sub playing a G-0. The top layer has two voices that are slightly spread and detuned to further widen the sound.



~ Full Bass



~ Top Layer



~ Bottom Layer



As you can hear, the full bass sounds wide despite the fact that the sub is mono. In general, keep frequencies below 100 Hz mono and central.



Optimal Sub Range



The sub becomes jarring when played in a register that is too high. In a register that is too low, it is inaudible. Therefore, the optimal range for a sub to play in is D0 to E1. Anything above E1 won’t really sound like a sub and anything below D0 risks being inaudible on most systems or simply won’t have enough impact.



~ Here is a sine wave in Massive playing a G0. This is an optimal note for the sub.



~ This is an F1 (Sounds a little harsh)



~ This is a C#0 (Difficult to hear)





5) POOR BALANCE



In order to have a mix that sounds compact and tight, you’ll have to make good use of meters and other tools that give you visual representations of your mix.



Stereo Balance



When you pan channels in different directions without justification, you increase the chances of having an unbalanced combined output. This can cause problems when you have master or group effects (effects inserted on a stereo mix) that process the left and right channels individually.

The best way to judge if your left and right channels are balanced is by looking at the built-in meters. It’s a no-brainer. The two green bars represent the left and right channels, respectively. Keep an eye on individual channel metering, but most importantly, on your master channel. The image below shows that the left channel is significantly louder than the right one in my mix. If you’re sustaining a reading like this on your master channel for more than a moment, you should have a look at your individual channels and fix the offset.



Top Mistakes 2 - Level



Mono Compatibility



With regards to other widening techniques like pseudo-stereo or mid-side processing, extra care should be taken as these can also create asymmetrical stereo images. In addition, these techniques often reduce mono compatibility, which will affect the mix in a live setting (club systems are always mono). Summing left and right to check for mono compatibility is a critical task for any mixing engineer. A mix that sounds good in mono will naturally sound better and wider in a stereo setting. Not the other way around.

Here is an example of two wide stereo sounds being played in mono. The first example is how a mono compatible sum sounds. The second exemplifies the strange distortion that occurs when a sum is not mono compatible. Notice how the first example is much “tighter” than the second. Its tone is more confident and supported. The second example is a little “out-of-focus” compared to the first.







You’d have a problem if your lead would sound like the one in example 2. This is because different voices of the synth phase in ways that cause certain frequencies to be multiplied and others to be attenuated or eliminated. So, mono compatibility is an important step to get into the habit of checking. For more information on how to treat phasing, visit our article on Healthy Phase Relationships.

Note that the reason sub frequencies are kept mono and central is mono compatibility issues. This way, if anything is distorted on a summed live system, you know it’s not the sub!



6) UN-STABLE LEVELS



As you start paying more attention to level meters and analyzers in your DAW, you’ll realize how volatile they are. Often times, signals that sound like they are at a consistent volume are actually fluctuating a lot. When a mix is brought to mastering, too much variation in level will cause the limiter and compressor to work harder then they should have to in certain parts of the arrangement and not work hard enough in other parts. When too much signal is fed into these plug-ins, they will distort. And, the only way to properly mend this distortion is by adjusting the overall mix, which the mastering engineer can request if he/she desires. If you want more information on why it is important to stabilize the levels of your different channels, you can check my article Maximizing Loudness.

To demonstrate my point, here is a processed snare followed by the original. The two sounds are outputting at the same level in Lumit, but the first one sounds louder than the second. This is because a freeware saturator and a compressor/expander are processing it. What I’m trying to show is… at the same level reading in your DAW, there is still a margin of how loud the sounds are perceived. Because of this, it’s important to keep the level in Lumit as consistent as possible. You can get pretty far with that before you actually start damaging the sound.
