Produce Shimmering Echoes

Indeed, you must have encountered delay and echo plug-ins, and you may have wondered what the difference between the two is. If the truth is told, these two effects are ultimately the same; their origins really differ. Delay tends to be purely digital and often refers to digital delay lines. On the other hand, echo is a term used to refer to analog tape-based delays. Furthermore, the echo builds on the simple delay by adding regeneration or feedback to the mix. An adjustable amount of the delayed sound mixes back into the signal, creating multiple echoes.

Dedicated to Echoes

I am sure readers will agree that the echo is an audio effect that undoubtedly offers endless possibilities in music production. You can hear it in every record, from the past century to modern music. Therefore, in the following tutorial, I will try to demonstrate an excellent effect achievable with a specific delay unit. It sounds best when applied to instruments like acoustic guitars, piano, or strings. Nevertheless, it applies to any other instrument.

Shimmering Echoes in Time

Years ago, the brains behind Soundtoys (formerly Wave Mechanics) worked for a little company called Eventide New Jersey. While there, these geniuses created the now world-famous H-3000 Harmonizer®. It contained a new type of algorithm they called Reverse Shift. That new algorithm remained largely unused until a sound designer by the name of Andrew Schlesinger had a realization. Andrew found that using the algorithm, coupled with generous feedback and delay; one could create lush “Crystal-Like” echoes and shimmering effects that sounded incredible, especially on guitar.

Discovering Soundtoys Crystallizer

In the present day, Soundtoys developed a plug-in unit called Crystallizer modeled by the algorithm mentioned above. In addition to this, they also added a bunch of new parameters. By tweaking just a few knobs, you will hear that our instrument, an acoustic guitar, in this case, enters a different sound dimension. As you can see below, in a newly created project within the SoundBridge: DAW, I  have played an acoustic guitar sequence made by Ilya Efimov Nylon Guitar Bank that can be purchased and used within Kontakt by Native Instruments. Let us hear how it sounds unaffected.

~Acoustic Guitar Unprocessed

Next, I placed the guitar chords and solo tracks on the group track for better control. Consequently, I have put a Crystallizer plug-in unit in this group. Upon opening the Crystallizer interface, we can see several parameters. I will control and try to explain them.

Parameters Explained

• The Mix control balances the shifted sounds created by the Crystallizer (wet) and the dry (unaffected) signal.
• The Pitch control allows you to adjust the pitch of the effect signal up or down (3) octaves (6-octave total range), with the maximum values being +3600/-3600.

• The Splice control determines the length of the section of audio. The values are in milliseconds, and the range of the knob is from 0-2050 ms (a little over 2 seconds)

• The Delay control allows you to insert a specific delay between the original signal and the effected signal.

• The Recycle knob is essentially a feedback control. It allows you to send the output of the effect signal back into the input at varying amounts. Turning the control up will generate repeating, spiraling pitch effects, and depending on the setting, the Pitch knob can create upward or downward spirals.

I will only automate the Mix and Recycle parameters. I want you to hear the effect in its full power.

~Acoustic Guitar with Crystallizer
